SaintyCo
ABC Linha Blister-Encartuchamento
ABC Blister Cartoning Line — equipamento farmacêutico da SaintyCo com suporte técnico especializado no Brasil.
Principais Características
- Max output: 300 -400 ampoules/minute; 160-240bottles/minute
- Fully integrates machine with blister packaging and cartoning machine
- Suporte Técnico Brasileiro
- Qualificação Especializada Brasileira
Detalhes do Produto
| Item | Descrição |
|---|---|
| Capacidade Máxima | 300 Ampoules/minute5 Ampoules per blister(1or2or3ml) |
| 160 Bottles/minute2ml Vial+1ml Ampoule(Combo pack) | 240 Bottles/minute2ml Vial+1ml Ampoule(Combo pack) |
| Max Forming area and depth | 245×130×35mm |
| Leaflet Size | (80-250)×(90-170)mm |
| Carton Material | 250-350g/m2 |
| Carton Size | (70-180)×(35-85×(14-50)mm |
| Air Compressor | 0.6-0.8Mpa ≥0.8m3/min |
| Leaflet Material | 60-70g/m2 |
| Power | 220/380V 50/60Hz 8Kw |
| Peso | 4,500Kg |
| Punch frequency | 25 cycles/min |
| Max. Forming area and depth | 245×130×35mm |
| Adjustable range of stroke | ≤130mm |
| Air compressor | ≥0.38m3/min (self -prepared) |
| Velocidade | 30-100 cartons/min |
| Carton | Quality requirement |
| Dimensão | (70-180)×(35-85×(14-50)mm |
| Leaflet | Quality requirement |
| Unfolded leaflet specification | (80-250)×(90-170)mm |
| Fold range | 1-4 fold |
